APPLICATIONS FOR 2 LAYER COATING DIES
For coating prefabricated pipes produced from PB , PEX, PERT, PP-R or similar plastic, also suitable for aluminum composite pipes. The pipes are then coated with a layer of adhesive, or EVOH or for example a layer of HDPE as a protective layer.
A vacuum tank, blower or undercarriage are available on request.
| Model | Pipe range in mm from – to |
max. heating each zone in kW | Zones incl. U-insert |
|---|---|---|---|
| 2/U12 G | 4 - 12 | 2,0 | 3 |
| 2/U20 G | 10 - 12 | 2,0 | 3 |
| 2/U25 G | 12 - 25 | 2,5 | 4 |
| 2/U32 G | 15 - 32 | 3,0 | 4 |
| 2/U42 G | 20 - 42 | 3,0 | 4 |
| 2/U55 G | 25 - 55 | 3,0 | 4 |
| 2/U75 G | 32 - 75 | 4,0 | 4 |
| 2/U90 G | 50 - 90 | 4,0 | 5 |
| 2/U125 G | 75 - 125 | 5,0 | 5 |
| 2/U160 G | 90 - 160 | 5,0 | 5 |
